Magnetic Bar is used for removing ferrous contaminants from free flowing material. All the ferrous particles like bolts, nuts, chips, damaging tramp iron can be caught and held effectively. So it provides a good solution of material purity and equipment protection. Magnetic filter tubes are constructed by strong permanent magnet with stainless steel shell. SS shell can be chosen from SS304, SS316 and SS316L. Either round or square shape bars are available for customers' requirements for special applications.
Size: Our standard magnetic bar is 25 mm (1 inch) in diameter and any length per customers' request up to 2500mm. Actually, diameter of round magnetic bar can be 10 mm smallest and largest to 101.6 mm . Magnetic Force: It subjects to customers' requirements. The highest magnetic strength of Dia. 25 mm can achieve 12,000 GS (1.2 Tesla). Of course, larger diameter, higher magnetic strength. Working Temperature: Our ordinary working temperature is 80, but if demand, we can make up to 350 to meet your special applications. How to select our products? Please advise us the above necessary information to make enquiry. If you aren't in a position to offer these information, please feel free to contact our engineer and acquaint us with the application environment and material condition.
|
