Products  The current position:Home - Products - Metal Detectors


  SEC series metal detector have high sensitivity, strong anti-interference ability, stable and reliable performance, size can be customized according to user's need.
Scope of application:
  Food processing, chemical industry, plastic recycling, crushing process, rubber production, wood and paper processing industries, used for detect the broken needle or non-ferrous metals such as: iron, copper, stainless steel wire in raw materials.
Product features:
1. In general, the installation of conveyor belt is horizontal.also can be installed slant.
2. SEC600 of the probe head can be separated;The conveyor belt need not to cut.
3. SEC700 of the probe head cannot be separated;The conveyor belt must through the metal detector.
4. Have a timer is used for adjust time of conveyor stop or start.
Relevant parameters:
Detection window height: 100-600mm.
Detection window width: 300-2000mm.
SEC600 sensitivity: iron ball more than 0.8 mm, stainless steel (SUS304) more than 2.0 mm.
SEC700 sensitivity: more than 0.8 mm any metal ball.
Power supply: 220 V, 50 Hz.(can be made according to user voltage)
Power: 100 W.
Alarm way: sound and light alarm, and automatically stop conveyor.
Installation dimensions (Lx W x Hmm) : made according to user request.
Weight: 45-100 kg.
